Models - KMC Controls MEP-7 Series Application Manual

Models

180 in-lb.
Model #
(20 N•m)
min.
MEP-7x01
MEP-7x02
MEP-7x03
7500 series
(x=5)
MEP-7x51
MEP-7x52
MEP-7x53
The MEP-72xx series (120 in-lb.) has been discontinued. Use the MEP-75xx series (180 in-lb.)—or, if less torque is required, an MEP-48xx (80
in-lb., non-fail-safe) or MEP-49xx (90 in-lb., fail-safe) instead.
To replace the MEP-70xx series (150 in-lb.), use MEP-75xx series (180 in-lb.).
To replace the MEP-77xx series (300 in-lb.), use MEP-78xx series (320 in-lb.).
*NOTE: The MEP-7200 series (120 in-lb.) has been
discontinued. Use an MEP-75xx (180
in-lb.)—or, if less torque is required, an
MEP-48xx (80 in-lb., non-fail-safe) or MEP-
49xx (90 in-lb., fail-safe) instead. Besides
maximum torque, the differences between
the MEP-7200 and MEP-7500 series include:
Powered Timing (Full Rotation)
MEP-72xx
MEP-75xx
Fail-Safe Timing (Full Rotation)
MEP-725x
MEP-755x
MEP-7xxx Direct-Coupled Actuators (up to 320 in-lb.)
Torque
320 in-lb.
Tri-state
(36 N•m)
(Floating)
min.
4
4
7800 series
(x=8)
4
4
75–90 seconds,
load dependent
90–115 sec., load
dependent
65–100 sec., load
dependent
80–115 sec., load
dependent
Control
0–10 VDC, 2–10
VDC, or 4–20 mA
Proportional Potentiometer
4
4
NOTE: See also the
Guide.
NOTE: Before Jan. 2014, MEP-7xx2 proportional
models had (besides the 4-20 mA input)
a 0–10 VDC input and 0–5 or 0–10 VDC
feedback. From 2014 through July 2015,
they had a 2–10 VDC input and 1–5 or 2–10
VDC feedback instead. Starting in August
2015, all these options were available and
selectable via a jumper and slide switch.
NOTE: When the 0–10 VDC input is selected (with
the jumper), selectable (with a switch)
feedback options are 0–5 or 0–10 VDC.
When the 2–10 VDC input is selected,
feedback options are 1–5 or 2–10 VDC.
4
Built-in Options
Feedback: Feedback:
10K ohm 0/1–5 or
0/2–10 VDC
4
4
4
4
KMC Actuators Selection
Applications Guide, AN1113A Rev. D
Fail Safe
4
4
4
