KMC Controls BAC-9300 Series Installation Manual

CONTENTS
Introduction .............................................. 1
Mount Controller ........................................ 1
Connect Sensors and Equipment .................. 2
Connect (Opt.) Pressure Flow Sensor ............ 3
Connect (Opt.) Ethernet Network .................. 3
Connect (Optional) MS/TP Network............... 4
Connect Power .......................................... 4
Power and Communication Status ................. 4
MS/TP Network Isolation Bulbs .................... 5
Configure/Program the Controller ................. 6
Sample (BAC-9311) Wiring .......................... 7
Input/Output Objects/Connections ................ 8
Replacement Parts ....................................10
Important Notices .....................................10

INTRODUCTION

Complete the following steps to install a KMC
Conquest™ BAC-9300 Series Unitary Controller.
For controller specifications, see the
kmccontrols.com. For additional information, see
the KMC Conquest Controller Application

MOUNT CONTROLLER

NOTE: Mount the controller inside a metal
enclosure for RF shielding and physical
protection.
NOTE: To mount the controller with screws on
a flat surface, complete the steps in
a Flat Surface on page
the controller on a 35 mm DIN rail
(such as integrated in an
enclosure), complete the steps in
DIN Rail on page
On a Flat Surface
1. Position the controller so the color-coded
terminal blocks
1
wiring.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
BAC-9300 Series Controller
data sheet
Guide.
1. Or to mount
HCO-1103
On a
1.
are easy to access for
NOTE: The black terminals are for power. The
2. Screw a #6 sheet metal screw through each
corner of the controller
1
On a DIN Rail
1. Position the DIN rail
at
controller is installed the color-coded terminal
blocks are easy to access for wiring.
2. Pull out the DIN Latch
3. Position the controller so that the top four tabs
5 of the back channel rest on the DIN rail.
3
On
4. Lower the controller against the DIN rail.
5. Push in the DIN Latch
rail.
/ 877.444.5622 /
Installation Guide
green terminals are for inputs and
outputs. The gray terminals are for
communication.
2 .
3 so that when the
until it clicks once.
4
6 to engage the DIN
Fax: 574.831.5252 / www.kmccontrols.com
2
5
4
