Chassis with cover removed
You can refer to the information on the inside of the cover regarding components
within the chassis.
Re-installing the NetBackup 5220 chassis cover
1.
2.
3.
Replace the chassis cover at the top rear of the NetBackup 5220 enclosure.
Slide the cover from the rear of the device towards the front.
Carefully line up both sides of the cover with the sides of the chassis itself. Do
not allow warping or damage to the cover.
Reinstall the single screw at the right front of the external chassis.
51
