38
Letter Component
A 280-pin Adaptive
B POST Code Diagnostic LEDs
C RMM3 Header
D Processor 1
E Back Panel I/O Ports
F System Identification LED
G System Status LED
H Memory 1 Fan Header
I CPU 1 Fan Header
J Processor 1 DIMM slots (qty 6)
K Processor 2 DIMM slots (qty 6)
L Processor 2
M CPU 2 Fan Header
N Memory 2 Fan Header
O Bridge Board Connector
P Front Panel Connector
Q Fan Board Connector
R 2x4 Power Connector
S System 1 fan header
T System 2 fan header
U Main Power Connector
V Low profile USB solid state drive header
W Power Supply SMBus
X USB header
Y LCP IPMB header
