RGB Adjustment

Use the selection key to select the icon, then press - or +. The screen
below will appear.
1024X768
Auto-Balance
CONTRAST
RED
GREEN
BLUE
BALANCE
RED
GREEN
BLUE
VERSION

Contrast Value Adjustment

Use the selection key to select the CONTRAST field, then press - & + to
get the best contrast optimization. You can adjust R,G,B simultaneously or
adjust each Red, Green, and Blue channel separately. You can also use this
field to change purity of the RGB levels.

Color Balance

Use the selection key to select the COLOR BALANCE field, then press - &
+ to get the best color balance effect or to separately set the RGB color
values. You can also use this field to change intensity of the RGB levels.
The easiest way to adjust the contrast and color balance setting is to use
auto-balance.
75 Hz/60 KHz
XGAD9B11-5100
3
20
18
19
49
50
26
