π H-2624
3M H128 2" HEAVY
DUTY TAPE DisPEnsEr

SPECIFICATIONS

Tape Width: 2" (48mm)
Tape Roll Diameter: Up to 5¾" (145mm)
maximum on a 3" (76.2mm) diameter core

LOADING

1.
Slide tape roll over flange. Dispense tape with
adhesive side facing down. Press down on roll to
fully mount on hub. (See Figure 1)
PAGE 1 OF 2
1-800-295-5510
uline.com
INSTRUCTIONS
Figure 1
Flange
2. Thread end of tape through narrow guide slot. To
dispense the tape, hold the dispenser and pull the
leading edge of the tape from the roll. Allow the roll
to rotate freely on the dispenser. (See Figure 2)
Guide
Slot
Figure 2
1012 IH-2624

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-2624 and is the answer not in the manual?

Questions and answers

Related Manuals for U-Line H-2624

Summary of Contents for U-Line H-2624

  • Page 1 π H-2624 1-800-295-5510 uline.com 3M H128 2" HEAVY DUTY TAPE DisPEnsEr SPECIFICATIONS Tape Width: 2" (48mm) Tape Roll Diameter: Up to 5¾" (145mm) maximum on a 3" (76.2mm) diameter core INSTRUCTIONS LOADING 2. Thread end of tape through narrow guide slot. To Slide tape roll over flange.
  • Page 2 INSTRUCTIONS CONTINUED OPERATING 2. Pull the dispenser across the carton seam, applying 1. Apply approximately 2" (48mm) of tape to the side pressure to the tape roll to obtain a tight seal. of the carton. (See Figure 3) 3. Continue to tape approximately 2" (48mm) past the Figure 3 end of the box, down the side panel.
