H-2861
SOFPULL
AUTOMATIC
®
PAPER TOWEL DISPENSER
TOOLS NEEDED
Drill
Drill Bit
Dispenser x 1
ATTENTION: Read all instructions before using
the towel dispensing system.
TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL
SHOCK OR INJURY TO PERSONS:
1. Close supervision is necessary when this furnishing is
used by children or disabled persons.
2. Use this furnishing only for its intended use
as described in these instructions. Do not
use attachments not recommended by the
manufacturer.
3. Never operate this furnishing if it is not working
properly, if it has been dropped or damaged, or
dropped into water. Return the furnishing to a
service center for examination and repair.
NOTE: Recommended mounting height is 44"
from the floor to bottom of dispenser.
1.
Press button on top of dispenser to open cover.
(See Figure 1)
PAGE 1 OF 9
1-800-295-5510
uline.com
Phillips Screwdriver
Level
D-Cell Alkaline
IMPORTANT SAFETY INSTRUCTIONS
MOUNTING INSTRUCTIONS
Tape Measure
PARTS
Battery x 4
4. Never operate the furnishing with the air openings
blocked. Keep the air openings free of lint, hair and
the like.
5. Never drop or insert any foreign object into any
opening.
6. Do not use outdoors.
7.
Do not operate where aerosol (spray) products are
being used or where oxygen is being administered.
8. Do not mix old and new batteries.
9. Do not mix non-rechargeable and rechargeable
batteries.
Figure 1
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
NOTE: Mounting hardware is not
included with this item. When
mounting dispenser, ensure that
proper mounting hardware is used
for appropriate wall composition.
0521 IH-2861
