H-2307
GYM WIPES
DISPENSER
TOOLS NEEDED
Drill
Drill Bit
Dispenser x 1
CAN BE
MOUNTED
INVERTED
NOTE: When mounting for use with dry wipers,
the dispensers should be oriented with the
opening on the bottom. When mounting for
use with gym wipes, the dispensers should be
oriented with the opening on the top.
NOTE: Recommended mounting height is 48"
from the floor to bottom of dispenser.
NOTE: Ensure that proper mounting hardware
is used for appropriate wall composition as
enclosed hardware may not be compatible
with your wall surface.
PAGE 1 OF 9
1-800-295-5510
uline.com
Phillips Screwdriver
Level
PARTS
Key x 1
MOUNTING INSTRUCTIONS
Tape Measure
Screw x 4
1.
Insert the key into the lock on the side of dispenser
and turn clockwise to open cover. (See Figure 1)
Figure 1
2. Open dispenser cover and hold dispenser to ideal
mounting place on wall. (See Figure 2)
Figure 2
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
Wall Anchor x 4
0521 IH-2307
