Halton Rex Expander (RXP) - Installation, commissioning, and maintenance guide
No. Part
1 Front panel
2 Nozzles
3 HAQ control
(optional)
4 Actuator of HAQ
control (optional)
5 Plenum
6 Brackets
7 Spigot
8 Frame
9 Connection pipes
10 Coil/Heat
exchanger
1.0
Description
Pre-painted galvanised steel
Polyester-painted, white (RAL 9003), with special colours available.
Nozzle plate: galvanised steel
Painted galvanised steel
Electric actuator (shown in the figure): connecting cable length 0.9 m
Manual actuator: galvanised steel
Pre-painted galvanised steel
Polyester-painted, white (RAL 9003)
Galvanised steel
Galvanised steel
Pre-painted galvanised steel
Polyester-painted, white (RAL 9003), with special colours available.
Copper. ø 12 mm with a wall thickness of 0.9–1.0 mm, fulfilling the
requirements of European Standard EN 1057:1996.
Pipes: copper
Fins: aluminium
