Solid State Logic C100HDSS Installation Manual page 59

Digital I/O Card ('942)
AES/EBU In 1–8 (9–16, 17–24, 25–32)
Location:
AES/EBU IN
Connector Type:
Cct
9 - 16 1 - 8
25 - 32 17 - 24
AES/EBU Out 1–8 (9–16, 17–24, 25–32)
Location:
AES/EBU OUT
Connector Type:
Cct
9 - 16 1 - 8
25 - 32 17 - 24
BNC Breakout Panel
1 2 9
3 4 11
5 6 13
7 8 15
942 DIO
25-way D-type female
Hot Cold
1
24 12
2
10 23
3
21 9
4
7 20
5
18 6
6
4 17
7
15 3
8
1 14
942 DIO
25-way D-type female
Hot Cold
1 24 12
2 10 23
3 21 9
4 7 20
5 18 6
6 4 17
7 15 3
8 1 14
(For 75Ω card version)
IN
10 17 18 25
12 19 20 27
14 21 22 29
16 23 24 31
Screen Notes
25 Pin 13 unused
11
22
8
19
5
16
2
Screen Notes
25 Pin 13 unused
11
22
8
19
5
16
2
26 1 2 9 10
28 3 4 11 12
30 5 6 13 14
32 7 8 15 16
Appendix C – Connector Pinouts
OUT
17 18 25 26
19 20 27 28
21 22 29 30
23 24 31 32
Page 55
