Appendix C: Connector Pinouts
Connector Pinouts – C100HDS Console
TB Out
Location: Connector panel
Connector Type:
Pin Description
1 Chassis (screen)
2 + signal
3 - signal
Meter Inputs – Analogue
Location: Connector Panel
Connector Type:
Pin Description
1 Circuit 1 input
14 Circuit 1 input
2 -
15 Circuit 2 input
3 Circuit 2 input
16 -
4 Circuit 3 input
17 Circuit 3 input
5 -
18 Circuit 4 input
6 Circuit 4 input
19 -
7 Circuit 5 input
20 Circuit 5 input
8 -
21 Circuit 6 input
9 Circuit 6 input
22 -
10 Circuit 7 input
23 Circuit 7 input
11 -
24 Circuit 8 input
12 Circuit 8 input
25 -
13 -
Note. If both the RTW phasescope and mechanical meters are fitted refer to the RTW circuit allocations.
XLR 3-pin male
Notes:
25-way D-type male
Notes: VU or PPM only
+ Left meter
-
+ -
-
+ Right meter
-
+ -
-
+ -
-
+ -
-
+ -
-
+ -
-
Appendix C – Connector Pinouts
Notes: RTW10830
Input 1
And Left VU/PPM meter
Input 2
And Right VU/PPM meter
Input 3
Input 4
Input 5
Input 6
Input 7
Input 8
