Introduction - Solid State Logic C100HDSS Installation Manual

C100HDS Installation Guide
Section 1 – Introduction
The object of this manual is to provide purchasers of the C100HDS™ Console, Blackrock™ processor and RIO
stageboxes with information in the following areas:
•
•
•
•
•
•
The information provided by this manual is relevant to all of the versions of the C100HDS.
Those aspects of the C100HDS system which may be subject to specific customisation – Master Channel layout and meter
panel as examples – will be documented in the Custom Specification information for a specific console.
The Custom Specification information, which details the actual console as built, will be found in Section 10 of the console's
Service Manual.
Page 2
Safety considerations
Installation requirements
Items supplied: – Main components and optional items
Installation: – Physical assembly
– Electrical connections and cabling
– System options
Specifications and Physical dimensions
Pinouts of standard connectors
