Section 4 System Components
System Options
External Keyboard
There is an inbuilt software keyboard included in the C100 system; this is accessed via the centre section touch screen.
Alternatively an external USB computer keyboard and or USB mouse/trackball may be connected to the audio connector
panel using the connectors provided ('USB1' and 'USB 2'). The diagram opposite shows the location of these connectors.
Script Tray
The script tray is an 8-channel wide movable transparent panel which fits over a channel bay. It has rollers fitted to allow
it to move along the length of the desk.
The script tray does not require modifications to the console and can be added to existing consoles.
Loudspeaker Shelf
A flat secure shelf is available for the positioning of loudspeakers, monitors etc. Each shelf is 400mm wide by 253mm deep.
A shelf is securely attached by locating under the front of the top trim and then screws are used to fix to the console's
back panel.
TFT External Input
This option adds an input switcher to any of the channel bay TFT screens so that it can then be switched to display the
signal from an external XGA (1024x768) video input. The switchover may be effected either by a GPI closure triggered
from a free button or by one of the unused latching switches located on the meter panel (see page 43).
Because it is necessary to install additional hardware within the console frame when adding this option, a maximum of
three of the four channel screens on the 32-channel console can be modified.
LCD Phasescope
The Centre Section of the console has space reserved specifically for an LCD phasescope surround monitor. Three
versions of phasescope are available to order: The RTW10830 which features 8 channels of digital and 8 channels of
analogue input with loop-through outputs; the DK Audio MSD600C with 6 channels of digital input and the MSD600M
which can accommodate varying input and output options by using plug-in modules.
The RTW and the MSD600C units are provided in standard configurations. The MSD600M meter can be adapted to suit
specific applications so its installation options should be discussed with SSL's Project Engineering department.
