Section 5
Meters and Phasescope
The Centre Section of the C100HDS console is fitted with two off analogue moving-coil meters. The meters supplied as
standard are VU scale but PPM versions can be specified. In addition, the Master Section can also be fitted with an LCD
phasescope. Three standard phasescope types are available to order: the DK Technologies MSD600C-5.1 or MSD600M++
or the RTW10830 SurroundMonitor.
The RTW 10830 has eight digital input signals (with loop-through outputs) and eight analogue input signals plus a remote
control port. Note that two of the analogue input signals will be split inside the console and also be used to feed the left
and right mechanical meters.
The MSD600C-5.1 phasescope has inputs for 6 digital signals (3 AES/EBU pairs) plus a serial diagnostic port.
The MSD600M++ uses the same display panel as the 600C meter but has slots at its rear into which a range of input and
output interface cards can be fitted. Cards are available in different combinations of analogue and digital I/O. It is therefore
important to discuss individual requirements with SSL's Project Engineering Department prior to order; some
combinations of I/O may not be able to be accommodated due to limited connector availability.
The inputs to the meters are accessed via two 25-pin D-type connectors mounted on the connector panel. The analogue
inputs use a male connector and the digital inputs use a female. Cable connections to the meters and phasescope will need
to be run between the RIO and the Console. Both balanced analogue and 110Ω digital cables may be necessary depending
on configuration. These cables are not supplied by SSL.
The signals used to feed the meters could be paralleled from the console main output busses or independent feeds from
the appropriate output card.
Refer to pages 51 and 52 for the meter connector pinouts.
It is the responsibility of the facility to ensure that all cabling required to enable correct operation of the VU and
phasescope meters is installed prior to the console being commissioned.
