Section 5
Blackrock to Console Surface Connection
Network Cables
The Blackrock processor is equipped with two separate network connections. Both use standard RJ45 termination and
cabling but are different protocols so must be kept separate at all times.
The first is labelled 'SSL' and is reserved for the connections to the console control surface and the optional redundant
Blackrock processor. The second connection is a standard TCP/IP Ethernet port which should be linked to a PC within
the facility's internet network. This machine can then be used for project backup, software updates and for SNMP status
reporting and maintenance support.
The SSL network connection is the only data link required between the Blackrock processor and the C100HDS console.
The recommended configuration is to use two separate data cables in parallel.
Single Blackrock Systems
a) Connect the two off 0.5m network cables supplied to the Blackrock rear panel as shown opposite.
b) Connect the two off console network cables supplied as shown opposite. Length will be as specified at time of
order.
c) Connect the Blackrock TCP/IP port to the Ethernet network port of a suitable PC. If using a direct connection
then a network cable of the 'crossover' type will be necessary. If the connection is via a standard network switch
or hub then standard pin-pin cables can be used.
Refer to page 37 for further details of configuring the PC for file transfer.
Systems with Redundant Blackrock
a) Connect the two off 0.5m network cables supplied to both the master and redundant Blackrock rear panels as
shown opposite.
b) Connect the two off console network cables supplied to each Blackrock processor as shown opposite. Length will
be as specified at time of order.
c) Connect the supplied 1m SSL network cable between both Blackrock processors.
d) Connect the TCP/IP ports from both Blackrock processors to an Ethernet hub or switch (not supplied). The PC
being used for project backup etc. will need to be connected to the same network.
Alternatively, If a PC is not being used or a hub/switch is not available, then the TCP/IP ports of the Blackrock
processors must be linked together using a single 'crossover' type Ethernet lead.
Refer to page 37 for further details of configuring the PC for file transfer and project backup.
If for either system a MORSE router has been specified then this must also be linked to the SSL network and can
optionally be linked to the TCP/IP network.
