Section 5

Talkback and Oscillator

Talkback Connection
The C100HDS console contains a built-in talkback microphone and amplifier. The microphone is located on the Centre
Section master tile adjacent to the main monitor pot. The Mic amp circuit features an inbuilt compressor and the output
signal is balanced and at line level. The TB output signal is available on an XLR 3-pin male mounted on the console
connector panel.
It will be necessary to install a single balanced audio cable between the talkback output connector on the console and the
analogue input DL connector in the RIO. The circuit chosen can then be assigned as the talkback source via the console's
routing system.
Oscillator Connections
The C100HDS features an inbuilt software oscillator. This signal can be assigned to any output without additional cabling.
Alternatively, an external oscillator (either analogue or digital, mono or stereo) may be used. In this instance one or two
circuits should be allocated on the appropriate input card; these signals can then be allocated via the touchscreen.
Refer to Appendix C for connector pinouts.
It is the responsibility of the facility to ensure that any cabling necessary to make use of the talkback and oscillator
functions is installed prior to the console being commissioned.
