Solid State Logic C100HDSS Installation Manual page 56

C100HDS Installation Guide
Meter Inputs – Digital
Location: Connector panel
Connector Type:
Pin Description
1 Circuit 1 input
14 Circuit 1 input
2 n/c
15 Circuit 2 input
3 Circuit 2 input
16 n/c
4 Circuit 3 input
17 Circuit 3 input
5 n/c
18 Circuit 4 input
6 Circuit 4 input
19 n/c
7 Circuit 5 input
20 Circuit 5 input
8 n/c
21 Circuit 6 input
9 Circuit 6 input
22 n/c
10 Circuit 7 input
23 Circuit 7 input
11 n/c
24 Circuit 8 input
12 Circuit 8 input
25 n/c
13 n/c
Phase Scope*
(Diagnostics and Control)
Location: Connector panel
Connector Type:
Pin
1
6
2
7
3
8
4
9
5
*Connector will be fitted to one spare cutout on connector panel (D1–D3). Refer to console specification manual for
actual location
Page 52
25-way D-type female
Notes: MSD600C–5.1
+ AES/EBU in 1/2
-
+ AES/EBU in 3/4
-
+ AES/EBU in 5/6
-
+ -
-
+ -
-
+ -
-
+ -
-
+ -
-
9-way D-type female
Notes: MSD600
Chassis
-
Rx Data
-
Tx Data
-
-
-
-
Notes: RTW10830
AES/EBU out 7/8
AES/EBU out 5/6
AES/EBU out 3/4
AES/EBU out 1/2
AES/EBU in 7/8
AES/EBU in 5/6
AES/EBU in 3/4
AES/EBU in 1/2
Notes: RTW10830
Switch common
Mode
Select
Memo
Gain
Reset
Shift
-
-
