Section 5
I/O – MicAmp Card (SSL ref. 968)
Each micamp input card provides 12 high quality microphone circuits. The inputs are accessed via standard XLR-3 female
connectors.
Refer to Appendix C for the connector pinouts.
SSL is able to supply mating connectors if requested, (at additional cost).
It is always highly recommended that the 48V phantom power is switched off (via the console control surface) before
connecting any microphones.
I/O – Analogue input/output Card (SSL ref. 944)
The analogue card provides 24 circuits of electronically balanced input and output. These circuits are accessed via Canon
DL 96-way female connectors; mating connectors are available to order.
Refer to Appendix C for the connector pinouts.
The default line-up level for analogue I/O is 0dBFS = +18dBu. This level may be globally altered and can range from +9dBu
to +24dBu. The value can be adjusted from a setup screen to match the standard operating level for the facility.
When assigning analogue card output channels as insert sends, the routing system will automatically assign the same
input channel number as the corresponding return. It is therefore necessary to physically wire outboard equipment so
that circuit allocation follows this arrangement.
Installation Wiring
Page 31
