RH Baby&child JAMESON STORAGE CONVERSION CRIB Assembly Instructions Manual page 7

STEP 2
MATTRESS SUPPORT ASSEMBLY
STEP 2.1
Attach the support arms to the mattress support, using Allen bolts
(CC), lock washers and plain washers. See DETAIL B.
STEP 2.2
Hang the mattress support on both side panels by using Allen bolts
(CC), lock washers and plain washers to attach the support arms
into the fixed nuts in the side vertical rails of the side panels. See
DETAIL C.
WARNING:
Set the mattress support to the desired height by adjusting the
support arms. The mattress support should be at it's highest setting
for newborns, then adjusted to the lower positions as the child
grows and becomes mobile. Once the child is able to stand, the
mattress support should be at its lowest position.
HARDWARE NEEDED FOR STEP 2
(CC) 1/4" x 13/16 " Allen Bolt = 8 pcs
Lock Washer 1/4" = 8 pcs
Plain Washer 1/4" = 8 pcs
Support Arm
(CC)
Allen Wrench = 1 pc
(CC)
Plain Washer
Lock Washer
DETAIL C
Support Arm
Support Arm = 4pcs
DETAIL B
7/12
