1-5 Layout Diagram & Jumper Setting Without CrossFire
Support
ATX 12V Power Connector
PS2 KB/Mouse Port
USB Port
RJ45 Over
USB Connector
Audio Connector
SFAN1
PCI Express x1
Realtek RT8101E
10/100 LAN
PCI Express x16
I/O Controller Chip
PCI Slot
SPDIF
Realtek ALC665
Audio Decode
COM1
Audio
Parallel
CDIN
Connector
IR Connecter
CPU Socket AM2
CPU FAN
AMD SB600
USB Port
(USB3, USB2, USB4)
USB Power On Jumper (JP3)
5
DDR2 Socket x 2
ATX Power Conn.
Floppy Connector
ATA 133 IDE
Conn.
AMD 480X Chipset
4MBit Flash
ROM BIOS
Serial-ATAII Connector
(SATA II 1, 2,3,4)
Front Panel Connector
SFAN2
Speaker Connector
Power LED Connector
(IDE1)
Clear CMOS (JBAT)
