Specification

Spec
Design
Chipset
CPU Socket AM2
Memory Socket
Expansion Slot
(CrossFire Supported
Edition)
Expansion Slot
(With no CrossFire
Edition)
Integrate IDE and
Serial ATA2 RAID
Optional LAN
6CH-Audio
(Option)
HD 8-CH
Audio
(Option)
BIOS
Multi I/O
∗ ATX form factor 4 layers PCB size: 29.5cm*22.5cm
∗
AMD 480X Chipset and AMD SB600 Chipset
∗ Support 64bit AMD AM2 940-Pin package utilizes Flip-Chip
Pin Grid Array package compatible processor
∗ Support for HTT 1GHz AMD Athlon 64 X2 processor and
Athlon 64, and HTT 800MHz Sempron Processors
∗ 240-pin DDR2 Module socket x 4
∗ 240-pin DDR2 Module socket x 2
∗ Support 4 / 2 pcs DDR2 533 / DDR2 667 / DDR2 800 Modules
Expandable to 8.0 / 4.0GB
∗ PCI-Express x16 slot 2pcs; one delivers up to 8 GB/s of
concurrent bandwidth with the "Switch Card" being installed,
and it offers 8-LANE + 8-LANE bandwidth for CrossFire
Activating.
∗
PCI-Express x1 slot 1pcs delivers up to 512MB/s
∗
32-bit PCI slot x 2 pcs
∗ PCI-Express x16 slot 1pcs delivers up to 8 GB/s of concurrent
bandwidth.
∗
PCI-Express x1 slot 1pcs delivers up to 512MB/s
∗
32-bit PCI slot x 3 pcs
∗
One IDE controllers support PCI Bus Mastering, ATA PIO / DMA
and the ULTRA DMA 33/66/100/133 functions that deliver the data
transfer rate up to 133 MB/s.
∗
Four Serial ATA2 ports provide 300 MB/sec data transfer rate with
RAID 0, 1, 10 functions.
∗ Integrated Realtek RTL8111 PCI-E 10 / 100 / 1000 LAN /
RT8101E PCI-E10/100 LAN chip.
∗ Support Fast Ethernet LAN function of providing 10Mb /
100Mb 1000 Mb/s or 10Mb / 100Mb/s data transfer rate
∗ Realtek 6-channel ALC655 AC'97 Audio Codec onboard
∗ Audio driver and utility included
∗ Realtek ALC880 Azalia HD 8-channel Audio Codec integrated
∗ Support 8-channel 3D surround & Positioning Audio
∗ Audio driver and utility included
∗ Award 4MB Flash ROM
∗ PS/2 keyboard and PS/2 mouse connectors
∗ Floppy disk drive connector x1
∗ 1* Parallel port of 25-pin Block / 1 * Serial port of 9-pin Block
∗
1 * SPDIF of 9-pin Block
∗ IR connecter with 5-pin block x1
∗ USB2.0 port x 4 and headers x 6 (connecting optional cable)
∗
Audio connector (Line-in, Line-out, MIC/ 8CH Audio)
