4-3 The Introduction of DIY COOL Function

Advanced Thermal Solution System for PWM (The active cooling fan is Optional)
"DIY COOL" function is the unique thermal solution for PWM. The special and cost-effective design
can be the exhaust valve of exhausting the heat generated by PWM effectively. With the small but
quiet active 55mm cooling fan to decrease the temperature of PWM, we can extend the MTBF of the
capacitors up to 30% and get more stability of the system working under the higher and higher
frequency in the future.

4-4 The Introduction of BIOS BACK Function

Advanced BIOS Back & Recovery Function
"BIOS Back" function is automatically activated when the original BIOS malfunction occurs. When it
occurs to BIOS malfunction, the BIOS BACK function will be activated automatically, then the
system will restart to reload the BIOS backup to the system boot up menu as the following figure. It
takes 4 to 8 seconds to get into the boot up menu and here comes the message, "Warning! Now
System is BACKUP BIOS. Please reflash primary BIOS." after system reboots. And then, please
follow the OSD to press "F1" button to continue to log on your operation system.
Phoenix – Award WorkstationBIOS V6.00PG
Copyright © 1984-2006, Phoenix Technology, LTD
(m2a481t0b) EVALUATION ROM – NOT FOR SALE
Main Processor : AMD Athlon™ 64 X2 Dual Core Processor 4600+
Memory Testing : 458752 OK+ 64M shared memory
Memory Speed is : DDR2 533 , Dual Channel , 128-bit
IDE Channel 0 Master : None
IDE Channel 0 Slave : None
SATA Channel 1
SATA Channel 2
Warning Now System is BACKUP BIOS. Please reflash primary BIOS.
CPU Temp:
System1 Temp:
F1
Press to Continue,
12/13/2006-RS485-SB600-6A666J1HC-00
Please make sure to Update the BIOS after getting into operation system, or the BIOS BACK function
will check your primary BIOS status every time, and it may cause your inconvenience to.
