Ethernet
COM
Connect a watt-hour meter when
using the optional power
distribution function software
(DCS002A51).
Terminals for communication with
air conditioning system.
Dil
Pi3
COM
Pi2
Pi1
F2
LON
F1
This port is not used with
this model.
Terminal for the grounding wire.
Terminals for the power supply.
Connect single-phase power of
100 to 240 VAC, 50/60 Hz.
L2 L1
8
