intelligent Touch Controller
Model
DCS601C51
MAC ADDRESS
●
Thank you for purchasing intelligent Touch Controller.
●
This operation manual contains notes for safe use of the
product.
For correct use, be sure to read this manual
carefully before use.
Store this manual close at hand so that it can be referred
to as required.
Use smart and save smart
Hardware Manual
Before use
Safety Instructions
Maintenance
Maintenance
When Leaving the Product
For Your Information
We use recycled paper for making this operation manual.
1
3
4
6
7
7
8
12
13
14
Advertisement
Table of Contents
Related Manuals for Daikin DCS601C51
Summary of Contents for Daikin DCS601C51
-
Page 1: Table Of Contents
Part Names and Functions Maintenance Precautions Maintenance LCD Maintenance When Leaving the Product Turned OFF for a Long Time Model Troubleshooting DCS601C51 For Your Information Options MAC ADDRESS Specification After-sales Service ● Thank you for purchasing intelligent Touch Controller. ●... -
Page 2: Be Sure To Follow The Instructions Below
Safety Instructions Be sure to follow the instructions below Read the manual carefully in advance for correct use Instructions given here are classified into the following two categories. Instructions in both categories are important for safety and must be duly followed. Failure to follow the instruction may lead to serious consequences including death or Warning serious injury. - Page 3 Caution Notes on use for users Do not wash the controller Be sure to operate with the touch pen provided. with water. Failure to follow the instruction may lead to Washing may lead to damage or failure. electric shock. No exposure to water allowed! To clean, be sure to stop operation and turn the Do not install the controller in a place subject...
-
Page 4: System Overview
System Overview This intelligent Touch Controller is capable of controlling/monitoring up to 64 groups of indoor units (hereafter “groups”). The main functions of the intelligent Touch Controller include: 1. Collective starting/stopping of operation of the indoor units connected to the intelligent Touch Controller. 2. -
Page 5: Part Names And Functions
Part Names and Functions Front and Side View PCMCIA Card Slot Color LCD with Touch Panel Touch Pen Used when using the optional Provides a display for monitoring Use the touch pen for operation. Power Proportional Distribution and operation. Be sure to use the touch pen for (DCS002C51) or updating the Be sure to use the touch pen operation. - Page 6 Terminals on the Back of intelligent Touch Controller Terminal block for power supply Connect to AC100-240V power supply. RS232-C connector for Terminal size is M4. D3-NET Plus adapter Modem connector for AIRNET Using D3-NET Plus adapter When using AIRNET service, being sold as an accessory, connect it to the telephone line.
-
Page 7: Precautions
Precautions Internal Battery Enable(ON)/Disable(OFF)Switch The intelligent Touch Controller is equipped with internal batteries in order to run the clock during blackouts as well as to save data during blackouts when using the optional Power Proportional Distribution. The batteries can be enabled and disabled using the switches shown in the figure below. The clock and Power Proportional Distribution will not function properly when a blackout occurs 「... -
Page 8: Lcd Maintenance
Maintenance LCD Maintenance ● When the surface of the LCD or the main unit of the intelligent Touch Controller is soiled, wipe the soil off with a piece of cloth soaked in a diluted neutral detergent and wrung sufficiently. Do not use thinner, organic solvent, strongly acid solution, etc. The print may fade or wear out and discolor. -
Page 9: Troubleshooting
Troubleshooting Before Having the Product Serviced Item Description and Corrective Action When Backlight Auto OFF is set for Backlight Setup of the The display of the intelligent intelligent Touch Controller, the light goes out if the screen is Touch Controller has gone out. left untouched for a certain time. - Page 10 Item Description and Corrective Action On the Monitoring screen, The intelligent Touch Controller is designed in such a way that buzzer sounds when an area the buzzer sounds when any part of the screen is pressed. It not allocated for a button for is normal.
- Page 11 Emergency Procedure for intelligent Touch Controller Failure Item Description and Corrective Action Failure occurs in the intelligent As a temporary measure before our service personnel investigates into the problem, turn OFF the power supply Touch Controller while the breaker of the intelligent Touch Controller. This allows all remote control is disabled with kinds of operation with the remote control of air conditioners in the intelligent Touch Controller...
- Page 12 When it is desired to adjust screen brightness, contrast and buzzer sound level Item Description and Corrective Action The screen brightness, contrast and buzzer sound level are Screen brightness, contrast factory adjusted properly before shipment, but in case where and buzzer sound adjustment the screen is hard to see and the buzzer is hard to hear, for is desired.
-
Page 13: Options
Options Connecting Unification adaptor allows using the contact for normal and abnormal operation signal and collective start/stop with a contact. For details, contact the vendor you purchased the product from. Also, by connecting D NET-plus adaptor, it is possible to operate and monitor the indoor units of 64 groups (intelligent Touch Controller plus D NET Ð... -
Page 14: Specification
Specification Specification Power AC100 - 240V 50/60Hz 10 W maximum Power consumption Normally-open contact Force stop input Contact current approximately 10 mA × × × × Size 107 (W 1.2kg Mass Dimensions The specification and appearance of the product may be modified for improvement without prior notice. -
Page 15: After-Sales Service
