¡Thank you for purchasing intelligent Touch Controller.
¡This operation manual contains notes for safe use of the
product.
For correct use, be sure to read this manual
carefully before use.
¡When you have read this manual, be sure to store it in a
place where the operator can conveniently refer to at
anytime.
In case of personnel change, be sure to give the manual
to the new operator.
Operation Manual
Before use
Operation
Maintenance
Use smart and save smart
Be sure to follow the instructions below
Screen and the Functions
Operation
Precautions
Maintenance
LCD Maintenance
When Leaving the Product
Turned OFF for a Long Time
Troubleshooting
For Your Information
Options
Specification
After-sales Service
1
3
4
5
7
9
13
15
32
41
87
88
88
89
97
98
99
