DIP switch
1
ON
1
2
3
4
5
6
7
8
9
10
0
1
ON
1
2
3
4
5
6
7
8
9
10
0
1
ON
1
2
3
4
5
6
7
8
9
10
0
How to set DMX address via DIP switch:
FUN=OFF
(the 10th DIP switch
DMX address value = the total value of (1-9), to get the place value when in "on"
position, otherwise will be 0.
E.g.1: Set initial address to 32.
ON
1
2
3
4
5
6
7
8
9
10
*
When DIP switch 1-9 are OFF, the defaulted initial DMX address is 1.
ON
RDM mode:
OFF
ON
DMX mode:
OFF
ON
Self-testing mode:
OFF
DMX
=OFF
)
E.g.2: Set initial address to 37.
ON
ON
1
2
3
4
5
6
OFF
001+004+032=37
The DIP switch 1-10 are OFF.
FUN=OFF (the 10th DIP switch = OFF)
Setting DMX addresses with dip switch 1-9
FUN=ON (the 10th DIP switch = ON)
mode
E.g.3: Set initial address to 178.
ON
ON
7
8
9
10
1 2 3 4 5
OFF
002+016+032+128=178
4
ON
6 7 8 9 10
OFF
