www.ltech.cn
3、两种DMX端口的连接示意图
终端电阻
LT-903-DIP
LT-903-DIP
LT-903-DIP
3针XLR并联连接
终端电阻
通风孔
LT-903-DIP
LT-903-DIP
LT-903-DIP
安装距离不少于20mm
RJ45并联连接
以上两种方式可以任意混合连接
安装注意事项： 请在解码器与解码器之间预留通风距离（最少20mm)，切勿堵塞通风孔，
否则会因设备散热不畅影响使用寿命。
8
