PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M8 Washer M10 Split
M10 Washer M10 Curved
Washer (80)–2
(63)–6 (64)–6 Washer (62)–2
M4 x 16mm M6 Bolt Set (67)–2
M8 Locknut M10 Locknut
Screw (56)–4
(60)–6 (77)–1
M8 x 20mm M8 x 38mm Bolt M10 x 20mm M10 x 38mm Screw (75)–2
Screw (61)–6 (59)–6 Screw (74)–5
M10 x 53mm Screw (73)–1 M10 x 60mm Bolt (72)–1
M10 x 70mm Screw (76)–2
