Pro-Form EASY STRIDER User Manual page 11

9. Apply grease to the right Crank Arm (13).
Next, identify the Right Roller Arm (7), orient it as
shown, and slide it onto the right Crank Arm (13).
Attach the Right Roller Arm (7) with an M8 x
20mm Screw (61), an Axle Cover (44), and an
M8 Washer (63).
Attach the Left Roller Arm (8) in the same
way.
10. Apply grease to the axle on the Right Roller
Arm (7).
Next, identify the Right Pedal Arm (9), orient it as
shown, and slide it onto the Right Roller Arm (7).
Attach the Right Pedal Arm (9) with an
M8 x 20mm Screw (61), an Axle Cover (44), and
an M8 Washer (63).
Attach the Left Pedal Arm (10) to the Left
Roller Arm (8) in the same way.
9
8
10
10
Grease
11
13
Grease
63
44
7
8
7
9
63
44
61
61
