Pro-Form EASY STRIDER User Manual page 10

7. Identify the Right Upper Body Arm (4) and the
Right Upper Body Leg (5), and orient them as
shown.
Insert the Right Upper Body Arm (4) into the
Right Upper Body Leg (5). Attach the Right
Upper Body Arm with three M8 x 38mm Bolts
(59) and three M8 Locknuts (60); make sure
that the Locknuts are in the hexagonal holes.
Do not fully tighten the Bolts yet.
Attach the Left Upper Body Arm (3) to the
Left Upper Body Leg (6) in the same way.
8. Slide the Right Upper Body Arm (4) onto the
right side of the Upright Axle (18).
Slide the Left Upper Body Arm (3) onto the left
side of the Upright Axle (18).
Then, tighten an M8 x 20mm Screw (61) with
an Axle Cover (44) and an M8 Washer (63) into
each end of the Upright Axle (18) at the same
time.
7
3
8
3
61
44
63
10
4
Hexagonal
Holes
60
60
59
59
6
5
18
4
63
44
61
