3.2 PXI-7921 Pin Assignments & Descriptions
43. COM2+
44. COM2-
45. COM3+
46. COM3-
47. CH18+
48. CH18-
49. CH19+
50. CH19-
51. CH20+
52. CH20-
53. CH21+
54. CH21-
55. CH22+
56. CH22-
57. CH23+
58. CH23-
59. 1WireloRef*
60. TRG_IN
61. S_ADV
62. SHDNn
*not used in two-wire mode
10 Signal Connection
•
22. +5 V
OUT
23. CH8+
24. CH8-
25. CH9+
26. CH9-
27. CH10+
28. CH10-
29. CH11+
30. CH11-
31. CH12+
32. CH12-
33. CH13+
34. CH13-
35. CH14+
36. CH14-
37. CH15+
38. CH15-
39. CH16+
40. CH16-
41. CH17+
42. CH17-
Table 1: Pin Assignment (2 wire)
