Savant® Super Pro Host (SVR-7100S) Quick Reference Guide

Box Contents

(1) Super Pro Host [SVR-7100S]
(1) Power Cord
(1) Magic Mouse 2
(1) Magic Keyboard w/Numeric Keypad
(1) USB-C to Lighting Cable
(2) Rack Rails (ships in a separate box)
(1) Quick Reference Guide [this document]

Specifications

Environmental
Temperature 50° to 95° F (10° to 35° C)
Humidity 5% to 95% Relative Humidity (non-condensing)
Dimensions and Weights
Height 8.67 in (22.02 cm)
Width 18.98 in (48.20 cm)
Depth 21.24 in (53.95 cm)
Weight 38.8 lbs (17.6 kg)
5U
Rack Space
Minimum Rack Depth 24.00 in (60.96 cm)
Power
Input Power 100-240V AC 50/60Hz, single phase
1280W at 108–125V or 220–240V
Maximum Power
1180W at 100–107V
Memory
RAM 32 GB
Compliance
FCC Part 15
Safety and
Emissions
RoHS Compliant
Minimum Supported Release
Savant OS da Vinci 9.3.2

Mounting

The SVR-7100S comes with rack rails. To install these
rails scan the QR code to the right or visit the
Support website and search for Install Mac Pro into a
rack to review the article to install the Host.

Additional Documentation

For additional information, refer to the following documents on the
Savant Customer Community at Savant.com
–
Savant Super Pro Host Deployment Guide (009-1633-xx)
Super Pro Host Quick Reference Guide | 009-1981-00
Copyright 2020 Savant Systems, Inc | 200922
CE C-Tick
Apple
1 of

Front Panel

A
C
Slide Rail Depress both at the same time to allow the
A
Locks Host to slide out on the rails.
Used as handholds to assist in pulling the Host
B
Handles
alone the rack rails.
(2) Thunderbolt 3.
C
Thunderbolt 3
(Reserved for future use)
D
Power LED Illuminates White when host is powered On.
Power On: Press while powered Off.
E
Power Button Power Off: Press and hold while powered On
until power LED goes out.

Side Panel

A
Slide
A
Mounting Mounting points for the included rack rails.
Points
Component Latch on both sides to remove the component
B
Access Latch access cover.
2
D E
B
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
