CIS VCC-4K2 Product Specification & Operational Manual

4k uhdtv cmos color camera
Hide thumbs Also See for VCC-4K2:
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-4K2
Rev. 905-0087-04
3G-SDI × 4ch
4K UHDTV CMOS Color Camera
VCC-4K2
Product Specification
& Operational Manual
CIS Corporation
©2017-2021 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-4K2 and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-4K2

Summary of Contents for CIS VCC-4K2

  • Page 1 VCC-4K2 Rev. 905-0087-04 3G-SDI × 4ch 4K UHDTV CMOS Color Camera VCC-4K2 Product Specification & Operational Manual CIS Corporation ©2017-2021 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Quick Reference Table for Shutter Settings ....................20 Factory Settings ............................21 Dimensions ................................22 Case for Indemnity (Limited Warranty) ........................23 Product Warranty ............................23 CMOS Defective Pixels ..........................23 Product Support ..............................23 ©2017-2021 CIS Corporation. All rights reserved.

  • Page 3: Handling Precautions

    □ The camera must not be used under conditions or environments other than those specified in this manual. 1.3 Disclaimers (Exception Clause) CIS should not be liable for any damages or losses if; damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God.

  • Page 4: Product Outline

    VCC-4K2 Rev. 905-0087-04 Product Outline VCC-4K2 is a 4K UHDTV color camera with 3G-SDI x 4ch interface. Using a 1.0” global shutter CMOS image sensor, the maximum frame rate achieves 60fps. Features CIS proprietary ISP, “Clairvu ” image processing engine for superb imaging quality and high speed processing.

  • Page 5: Specifications

    Off, 100%, 95%, 90%, 85%, 80%, 75% Color gamut BT.709, BT.2020 Master Pedestal -100 ~ 0 ~ +100 Pedestal (R,G,B) RGB independent: -100 ~ 0 ~ +100 Color balance RGB independent: 0 ~ 100 ~ 200 ©2017-2021 CIS Corporation. All rights reserved.
  • Page 6 (100G) for ±X, ±Y, and ±Z, Shock 6 directions. (Without packaging) Operational Temperature -5 ~ +45℃ Humidity 20 ~ 80%RH with no condensation. Storage Temperature -25 ~ +60℃ Humidity 20 ~ 80%RH with no condensation. ©2017-2021 CIS Corporation. All rights reserved.

  • Page 7: External Connector

    Model Name : BCJ-BPLHA (CANARE) Pin No. Description 3G-SDI output CH0 (Upper left) 3G-SDI output CH1 (Upper right) 3G-SDI output CH2 (Lower left) 3G-SDI output CH3 (Lower right ) Shell Connected to chassis GND ©2017-2021 CIS Corporation. All rights reserved.

  • Page 8: Camera Functions

    00:00:00.00 when power is ON, and when signals are input to the LTC IN terminal, time code switches to external time code. Under this condition, if no signal is input to the LTC IN terminal, internal time code starts. Signal Format : SMPTE Time code 0.5～2［Vp-p］ Signal Level : ©2017-2021 CIS Corporation. All rights reserved.

  • Page 9: Defective Pixel Correction

    For example, if the defective pixel is at (943, 0), the data is registered only to region 0. However, if the defective pixel is at (944, 0), the data is registered to both region 0 and 1. ©2017-2021 CIS Corporation. All rights reserved.

  • Page 10: Notes For Defective Pixel Correction

    “Set”), and the other is GU command (“G” for “Get”) to obtain information from the camera. Command Parameter 1 Parameter 2 Function Address Normally None To obtain camera setting information. (There are exceptions in some cases) Address Data (There may be more than one) To change camera settings. ©2017-2021 CIS Corporation. All rights reserved.
  • Page 11 【Example of SU command】 To set 30 to address 10 [Send] SU [sp] 10[sp] 30[¥r] [Returned value] SU [sp] 10[sp] 30[¥r] [¥n] [Echo back] [Returned value] [¥r] [¥n] [Linefeed] [Returned value] > [sp] [Prompt (> and space)] ©2017-2021 CIS Corporation. All rights reserved.

  • Page 12: Command List

    18: UHDTV 2-Sample Interleave 30p 444 (Level A) 19: UHDTV 2-Sample Interleave 29.97p 444 (Level A) 20: UHDTV 2-Sample Interleave 25p 444 (Level A) 21: UHDTV 2-Sample Interleave 24p 444 (Level A) 22: UHDTV 2-Sample Interleave 23.98p 444 (Level A) ©2017-2021 CIS Corporation. All rights reserved.
  • Page 13 ※Please refer to Section 5.4 Quick Reference Setting range: (77) Table for Shutter Settings. 1/13600 ~ 1/23.98s 1/13600s (0x4D~0xAAD6） 0： Average 1： Center-Weighted Metering mode This is to set metering mode. 2： Spot 3： Backlight Compensation ©2017-2021 CIS Corporation. All rights reserved.
  • Page 14 (*1) Due to physical limitation of the sensor and circuit, there are some cases that user cannot control values and limits of gain and shutter as designated by commands. User can check the actual values with Current Gain and Current Shutter commands. ©2017-2021 CIS Corporation. All rights reserved.
  • Page 15 This is to acquire the current Red Gain. Current Red gain None None (Dedicated to GU) This is to acquire the current Blue Gain. Current Blue gain None None (Dedicated to GU) ©2017-2021 CIS Corporation. All rights reserved.
  • Page 16 Equivalent to 1200% for HLG [HLG] 50% output level is regarded as 100% input level. Color saturation 0~200(%) This is to set color saturation. 0 : Off Noise reduction This is to set noise reduction. 1 : On ©2017-2021 CIS Corporation. All rights reserved.
  • Page 17 OSD menu. 3: Magenta Highlight color 4: Green If user specifies the same color as the 5: Cyan text color, error will occur because the 6: Yellow selected letters cannot be recognized. 7: White ©2017-2021 CIS Corporation. All rights reserved.
  • Page 18 SDI compatibility 0: Off ON however, changes made are not subject to mode 1: On reflect. Set this mode ON if you are using a receiving equipment, which outputs no image with HLG75 or BT.2020. ©2017-2021 CIS Corporation. All rights reserved.
  • Page 19  of pixels classified under [P] attribute. User can change only user register data, and cannot remove the factory setting data.  User cannot register the pixels already been registered as factory data.  ©2017-2021 CIS Corporation. All rights reserved.

  • Page 20: Quick Reference Table For Gain Settings

    6658043 006597FB 114.035 41.141 7473400 007208F8 128.000 42.144 8388608 00800000 143.675 43.148 9415894 008FACD6 161.270 44.151 10568984 00A14518 181.019 45.154 11863283 00B504F3 203.187 46.158 13316085 00CB2FF5 228.070 47.161 14946800 00E411F0 251.189 48.000 16461899 00FB304B ©2017-2021 CIS Corporation. All rights reserved.

  • Page 21: Quick Reference Table For Shutter Settings

    000016C1 1/250 4194 00001062 1/350 2995 00000BB3 1/500 2097 00000831 1/725 1446 000005A6 1/1000 1048 00000418 1/1500 000002BB 1/2000 0000020C 1/3000 0000015D 1/4000 00000106 1/6000 000000AE 1/8000 00000083 1/9600 0000006D 1/11200 0000005E 1/13600 0000004D ©2017-2021 CIS Corporation. All rights reserved.

  • Page 22: Factory Settings

    Noise Reduction Color Correction Auto Color Suppression Color Space BT.709 Text Color White Highlight Color Cyan Camera Setting Store/Load LTC Mode GenLock V Offset GenLock H Offset H Flip V Flip SDI Compatibility Mode ©2017-2021 CIS Corporation. All rights reserved.

  • Page 23: Dimensions

    VCC-4K2 Rev. 905-0087-04 Dimensions ©2017-2021 CIS Corporation. All rights reserved.

  • Page 24: Case For Indemnity (Limited Warranty)

    CIS applies defective pixel correction prior to the shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
