Analog input/output harness (H4), 22-pin white connector

Conn./Pin Color
H4/1 Lt. Green/Black
H4/2 Blue/White
H4/3 Dk. Green/Black
H4/4 Red/White
H4/5 Brown/Black
H4/6 Brown/White
H4/7 White
H4/8 Violet/Black
H4/9 Dk. Blue/Black
H4/10 Lt. Blue/Black
H4/11 Brown/Red
H4/12 Pink
H4/13 Violet
H4/14 Brown
H4/15 White/Blue
H4/16 Red/Blue
H4/17 Black/White
H4/18 Orange/Black
H4/19 Blue
H4/20 Green
H4/21 Gray
H4/22 Violet/White

RF Port harness (H5), 2-pin white connector

Conn./Pin Color
H5/1 N/A
H5/2 N/A

D2D harness (H6), 4-pin white (1) and black (2) connectors

Conn./Pin Color
H6/1 Blue
H6/2 Black
H6/3 Green
H6/4 Red

Temperature sensor harness (H7), 2-pin black connector (optional, 8556T)

Conn./Pin Color
H7/1 Black
H7/2 Black
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they
are low current and a relay may be necessary.
7
Description
(-) Parking Lights Output
1
(-) Ground When Running (status) Output
(-) Lock Output
1
(-) Trunk Output
1
(-) Horn Output
1
(-) AUX 1 Output
1
(+) AUX 2 Output
1
(+) AUX 3 Output
1
(-) Unlock Output
1
(-) Push-to-Start Output
1
(+) Siren Output
1
(+) Ignition Sense Input
(+) Door Input
2
(+) Brake Input
2
(-) Activation Input
2
(-) Valet Switch
2
(-) E-Brake Input (manual transmission)
(-) Instant Alarm Input
2
(-) Trunk Input
2
(-) Door Input 2
(-) Hood Pin Input
2
(AC) Tach Input
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
Temperature Sensor
Temperature Sensor
1
2
DS4+ TL2
