Type 2 - Directed Directechs DS4+ Installation Manual

Type 2

Wiring diagram
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Main Body
ECU
(Back)
Black
ENGINE
START
connector
STOP
11
1 7 19
2 8
20
3 9 21
10 22
11 23
12 24
Body ECU
13 25
(White 30-pin connector)
14 26
15 27
4
16 28
29
5 17
(-) Parking Lights: Pin 30
6 18 30
BRX: Pin 4
BTX: Pin 16
(-) Push-To-Start: Blue or Lt. Green, pin 7
7
6 5 4 3 2 1
14 13 12 11 10
9 8
HS CAN High: Red or Violet, pin 6
1
9
HS CAN Low: White
or Red, pin 14
(+) 12V: Pin 16
HS CAN High: Tan/Black: 2
Immo Data 2: Orange/Black: 7
Immo Data 1: Yellow/Black: 8
(-) Parking Lights Output: Lt. Green/Black: 1
(-) Push-to-Start Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
Siren
Hood Pin
(-) SLP: Green or
Lt. Blue, pin 4
7 6 5 4 3 2 1
Steering Lock
(black 7-pin connector)
Diagnostic Connector OBDII
8
(connector side view)
16
HS CAN Low: Tan: 1
(-) Hood Input: Gray: 21
DS4+
(-) Ground: Blue/Red: 2
Proper Fuse
Positioning
(-) SLP Output: Blue: 3
(+) 12V Input: Red: 6 & 12
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-11-22 Directed. All rights reserved.
).
).
DS4
DS4
DS4+
DS4+ TL2
