Grundfos PHP A-1 4.0 Instruction Manual page 34

PHP A-1 Instruction Manual / Warnings and fault messages
No Message
W9: monitoring:
W9
Tlmax over-run
Wl0: monitoring:
W10
Tlmin under-run
Wll:time changed due
W11
to da':11ight-saving
Wl2: underPressure in
W12
vesse1 l (PLlo)
Wl3: temPerat. 1imit
W13
sensor T2 exceeded
Wl4: monitoring:
W14
T2max over-run
Wl5: monitoring:
W15
T2min under-run
Wl6: makeuP
W16 EMCF-1 V remaining
amount<20%
Wl7: softening
W17 MWE remain.
caPacit':1<20%
Wl8: underPressure in
W18
vesse1 2 (PL2o)
34
Description
Built-in monitoring has been
activated: the set maximum
temperature at sensor T1
has been exceeded
Built-in monitoring has been
activated: the set minimum
temperature at sensor T1
has been under-run.
The time has been changed
due to daylight-saving.
Low-pressure has been
detected in vessel 1
(upper transmitter of level
measurement L1). Thus
pumps have been disabled.
Maximum temperature
at sensor T2 has been
exceeded. Degassing is
deactivated as long as the
temperature is too high.
After this it will be
enabled again.
Built-in monitoring has been
activated: the set maximum
temperature at sensor T2
has been exceeded
Built-in monitoring has been
activated: the set minimum
temperature at sensor T2
has been under-run
The remaining amount
for the makeup is less
than 20% of the set
maximum amount.
The remaining amount of
the softening cartridge from
MWE is less than 20%.
If the amount is completely
used makeup can't be
used anymore.
Low-pressure has been
detected in vessel 1
(upper transmitter of level
measurement L2). Thus
pumps have been disabled.
Check/Repair
Message is only an advice.
It doesn't affect the function
of the device. Check set
limit value eventually
Message is only an advice.
It doesn't affect the function
of the device. Check set
limit value eventually
Check time and date before
resetting this message.
Pumps get enabled again,
if pressure is in allowed
range and the message
is reset. First check if the
hose from the outside of the
membrane is clear.
Message is only an advice.
The Sensor T2 is decided to
disable degassing in such
situations with too high
temperatures.
Message is only an advice.
It doesn't affect the function
of the device. Check set
limit value eventually
Message is only an advice.
It doesn't affect the function
of the device. Check set
limit value eventually
Message is only an advice.
It doesn't affect the function
of the device. Check if
consumption is in line with
the usual consumption of
the plant, reset the amount
so the full amount is
available again.
Provide spare cartridge
in time and change it at
latest if the old capacity is
completely used.
Pumps get enabled again,
if pressure is in allowed
range and the message
is reset. First check if the
hose from the outside of the
membrane is clear.
Necessary device options
for this message
no (contained in every
configuration)
no (contained in every
configuration)
no (contained in every
configuration)
no (contained in every
configuration)
sensor T2
sensor T2
sensor T2
makeup module EMCF-1 V
makeup module EMCF-1 V
and softening MWE
level measurement 2
