Creative Playthings WILLIAMSBURG SH 3100-000 Assembly Manual

With wood roof
Hide thumbs Also See for WILLIAMSBURG SH 3100-000:
Table of Contents

Advertisement

Quick Links

Download this manual
WILLIAMSBURG
WOOD
MODEL #SH 3100-000
with
ROOF
ASSEMBLY MANUAL
Carefully read the owner's manual and all instructions
All hardware on this set is
before assembling your play set. It provides additional
specially coated for corrosion
information on the care and use of your play set.
resistance.
Creative Playthings takes great care to design its products
If non-Creative Playthings
with your child's safety in mind. However, only with careful
supervision and proper safety instructions, can you be
hardware is used, it must be
assured of safe play time on any product designed for
galvanized or stainless steel.
children.
This product is intended for single family home/residential use only
and not intended for use in any public setting. Placement in any public
setting constitutes a misuse of this product.
Creative Playthings
33 Loring Drive, Framingham, MA 01702
www.creativeplaythings.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WILLIAMSBURG SH 3100-000 and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings WILLIAMSBURG SH 3100-000

Summary of Contents for Creative Playthings WILLIAMSBURG SH 3100-000

  • Page 1 Creative Playthings takes great care to design its products If non-Creative Playthings with your child’s safety in mind. However, only with careful supervision and proper safety instructions, can you be...

  • Page 2: Assembly Safety

    • Avoid assembling your play set in poor weather conditions. • Wear proper clothing and safety equipment (safety glasses, boots, and gloves) while assembling your play set. WILLIAMSBURG WITH WOOD ROOF Page 2 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 3 Safe play area using recommended ground cover. Landscape Timbers 6' from WHICHEVER play structure. IS GREATER A FALL ONTO A HARD SURFACE COULD RESULT IN SERIOUS INJURY. WILLIAMSBURG WITH WOOD ROOF Page 3 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 4: Hardware Bag Contents

    Screw - #10 x 2" 17025-104 Screw #8 x 1-1/4" 17020-113 Screw - #10 x 2-1/2" 17020-107 Screw #10 x 2" 17036-1202 Lag Screw - 5/16 x 3" WILLIAMSBURG WITH WOOD ROOF Page 4 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 5: Pre Assembly Information

    Assembly PRE ASSEMBLY INFORMATION All hardware on this set is specially coated for corrosion resistance. If non- Creative Playthings hardware is used, it MUST be galvanized or stainless steel. CREATIVE PLAYTHINGS PLAY SETS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND INSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN.
  • Page 6 PLAY SET VIEW WILLIAMSBURG WITH WOOD ROOF Page 6 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 7: Component Parts

    Mounts have not been included, contact customer service. 3 ea 32404-102 Wall Slat - 5/4 x 6 x 31-1/2" 31820-102 Swing Mount - 4 x 4 x 39" WILLIAMSBURG WITH WOOD ROOF Page 7 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 8: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS YOUR CREATIVE PLAYTHINGS PLAY SET IS STAINED AT OUR FACTORY. STAINING IS NOT NEEDED AT THE TIME OF INITIAL ASSEMBLY. Re-staining Information: • Pigmented, exterior, water repellent stains are recommended and will provide an excellent barrier against moisture without hiding the natural wood grain or leaving a film that may later crack or peel.
  • Page 9 * Note: A Hex Bolt Assembly consists of one Hex Bolt, one Lock Washer, one Flat Washer and one Repeat with the other posts, sandbox end and Weld Nut. platform end. WILLIAMSBURG WITH WOOD ROOF Page 9 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 10 Finish the tower base by installing the second Sand- 5/16 x 4" box Side (T) Using four 5/16 x 4" hex bolt assemblies. Hex Bolts F r o WILLIAMSBURG WITH WOOD ROOF Page 10 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 11 Attach each inside stringer using two Screws 5/16 x 4" lag screws and flat washers as shown. Make sure the outside stringers and inside stringers align across the top edge. WILLIAMSBURG WITH WOOD ROOF Page 11 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 12 Place two Narrow Platform Boards (I) tightly against the platform ends on top of the stringers. Fasten the narrow platform boards to the stringers with six #10 x 2" screws on each board. WILLIAMSBURG WITH WOOD ROOF Page 12 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 13 Fasten the End Wall Supports (Z) to the corner posts above the platform ends using four 5/16 x 4" Hex bolt assemblies for each wall support. WILLIAMSBURG WITH WOOD ROOF Page 13 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 14 Ridge Cap Part A and into Ridge Cap Part B. Leave the screw head flush to the surface of Ridge Cap Part A. Ridge Cap Part A (BB) WILLIAMSBURG WITH WOOD ROOF Page 14 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 15 The access ladder must be mounted well clear of any swing accessories. Provide space to mount entrance slats and hand grips on either side of the access ladder. WILLIAMSBURG WITH WOOD ROOF Page 15 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 16: Step21 - Safety Rail

    Space the bottom of all wall slats approximately 1/2" above the platform surface. Hint: Use the Slide Mount (K) to make sure there is enough room for the slide. WILLIAMSBURG WITH WOOD ROOF Page 16 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)
  • Page 17 Evenly space the three wall slats between the entrance slat and the right rear corner post, as shown. Leave approximately 2". Fasten the Wall Slats using four #10 x 1-5/8" screws. #10 x 1-5/8" Screws WILLIAMSBURG WITH WOOD ROOF Page 17 © Copyright 2005, Creative Playthings 19688-300 Rev R (09-20)

  • Page 18: Step 26 - Hand Grips

    Locate the 1" Hole Caps in the hardware bag. Install hole caps into all the counter-bored holes to cover and protect the hardware. Save all instruction sheets and receipts in case it becomes necessary to contact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual.
