MODEL 60081-102
SWING BEAM
This Swing Beam must
be mounted to a Playtime
Series
gym. Refer to the
®
instructions provided with
your gym for extensive
safety information.
Read the owner's manual
before assembling your
Play-set, it provides addi-
tional information on care
and use.
Carefully read the all
instructions before pro-
ceeding with the assem-
bly or use of your new
Play-set.
We take great care to
design our products with
your child's safety in
mind. Only with supervi-
sion and proper safety
instruction, can you be
assured of safe play on
any children's product.
1/4 x 3" Hex Bolt
5/16 x 1-1/2" Hex Bolt
5/16 x 3" Hex Bolt
5/16 x 4-1/2" Hex Bolt
5/16 x 5-1/2" Hex Bolt
G
B
C
E
Swings & Trapeze packed separately.
Part number: 50537-201
Hardware
Swing Hanger,
Screw Type
(Not to Scale)
5/16" Flat Washer
5/16 Lock
™
1/4" Flat Washer
1/4" Lock
Washer
Washer
By
Parts list on next page
1/4" Weld
Nut
5/16" Weld
Nut
1/4 x 3" Lag Screw
#8 x 2-1/2" Screw
#6 x 1/2" Pan
Head Screw
H
D
A
K
J
