LEXINGTON
MODEL #SH 6100-000
WITH WOOD
ASSEMBLY MANUAL
ROOF
Please read the owner's manual before assembling your play set.
It provides additional information on the care and use of your play
set. You must carefully read the entire instruction manual before
proceeding with the assembly or use of your new play set.
Creative Playthings takes great care to design its products with your child's safety
in mind. However, only with careful supervision and proper safety instructions,
can you be assured of safe play time on any product designed for children.
This product is intended for single family home/residential use
only and not intended for use in any public setting. Placement in
any public setting constitutes a misuse of this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEXINGTON SH 6100-000 and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings LEXINGTON SH 6100-000

Summary of Contents for Creative Playthings LEXINGTON SH 6100-000

  • Page 1 You must carefully read the entire instruction manual before proceeding with the assembly or use of your new play set. Creative Playthings takes great care to design its products with your child’s safety in mind. However, only with careful supervision and proper safety instructions, can you be assured of safe play time on any product designed for children.

  • Page 2: Assembly Safety

    • Until assembly is complete, DO NOT let your children use the play set. • Never fasten anything not approved by Creative Playthings to your play set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.

  • Page 3: Safe Play Area

    • Any edging used to contain the ground cover must be beyond the Safe Play Area. (i.e.. Landscape Timbers) Safe play area using recommended ground cover. Landscape Timbers 6' from WHICHEVER play structure. IS GREATER A FALL ONTO A HARD SURFACE COULD RESULT IN SERIOUS INJURY. LEXINGTON Page 3 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)

  • Page 4: Hardware Bag Contents

    Lag Screw - 5/16 x 4" 17119-1209 Truss Head Bolt - 1/4 x 3" We have packaged more hardware than is required for assembly. 14161-400 Access Ladder Bracket LEXINGTON Page 4 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)

  • Page 5: Pre Assembly Information

    Assembly PRE ASSEMBLY INFORMATION All hardware on this set is specially coated for corrosion resistance. If non-Creative Playthings hardware is used, it MUST be galvanized or stainless steel. CREATIVE PLAYTHINGS PLAY SETS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND INSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN.
  • Page 6 Assembly PLAY SET VIEW LEXINGTON Page 6 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)

  • Page 7: Component Parts

    Wall Slats are provided. If additional Slats are not included, contact customer service. 31820-102 Swing Mount - 4 x 4 x 39" 3 Ea 32404-102 Wall Slat - 5/4 x 6 x 31-1/2" LEXINGTON Page 7 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)

  • Page 8: Maintenance Instructions

    Tighten as required and specified in these instructions. Do not over tighten. • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service.
  • Page 9 Corner Post. The holes should face the inside of the Gym. * Note: A Hex Bolt Assembly consists of one Hex Bolt, one Lock Washer, one Flat Washer and one Weld Nut. LEXINGTON Page 9 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 10 Platform Side (O) using two 5/16 x 4" Hex Bolt Assemblies through the holes on each end. Position the Platform Side (O) as shown in the illustration. Back Left Right Front LEXINGTON Page 10 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 11 Note: The right Platform Side has been omitted from the illustration for clarity. LEXINGTON Page 11 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 12 (V) using four 5/16 x 2-1/2" Hex Bolt Assemblies. Do not tighten these bolts yet. The Angle Braces (B) should be fastened so that the angled end is flat against the nearest Corner Post. LEXINGTON Page 12 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 13 Layout all the Platform Boards (N) on the Inside and Outside Stringers. Space the Platform Boards (N) evenly between the Narrow Platform Boards (I). Attach each Platform Board (N) using eight #8 x 2" Screws. LEXINGTON Page 13 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 14 STEP 14 - End Wall Supports: Fasten the End Wall Supports (AC) to the Corner Posts above the Platform Ends (V) using four 5/16 x 4" Hex Bolt Assemblies for each Support. LEXINGTON Page 14 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 15 An effort should be made to provide space to mount Entrance Wall Slats and Hand Grips on either side of the Access Ladder. (See steps 21 and 22). LEXINGTON Page 15 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 16 Note: When placing Wall Slats, leave no gap larger than 3-1/2" except at entrance or exit points. The right Wall Sup- port has been omitted from the illustration for clarity. LEXINGTON Page 16 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 17 Drive the screws until the heads are flush with the top of the Slide Mount. Do not over-tighten; over-tightening may cause the points of the screws to protrude through the bottom of the Platform Boards. LEXINGTON Page 17 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 18 5/16 x 4-1/2" Hex Bolt Assembly , as shown. Rafter Please note the smaller 2 x 3 Roof Rafters have been omit- ted from the illustration. Roof Block LEXINGTON Page 18 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 19 Make a final check and make sure that all the bolts and screws have been tightened. Locate the 1" Hole Caps in the hardware bag. Install Hole Caps into all the counter-bored holes to cover and protect the hardware. LEXINGTON Page 19 © Copyright 2005, Creative Playthings 19686-300 Rev N (01-19)
  • Page 20 Save all instruction sheets and receipts in case it becomes necessary to con- tact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. Please fill out the warranty card on the back of your owners manual. Your completed warranty card will allow us to quickly process warranty claims.
