YORKTOWN
MODEL #SH 6100-000
ASSEMBLY MANUAL
The Yorktown gym is built using the frame of the Lexington gym as a
base structure. When assembling the this gym, set aside the Lexington
instructions and follow the steps in this document.
Please read the owner's manual before assembling your play set.
It provides additional information on the care and use of your play set
You must carefully read the entire instruction manual before
proceeding with the assembly or use of your new play set.
Creative Playthings takes great care to design its products with your child's safety
in mind. However, only with careful supervision and proper safety instructions,
can you be assured of safe play time on any product designed for children.
This product is intended for single family home/residential use
only and not intended for use in any public setting. Placement in
any public setting constitutes a misuse of this product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YORKTOWN and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Playthings YORKTOWN

Summary of Contents for Creative Playthings YORKTOWN

  • Page 1 YORKTOWN MODEL #SH 6100-000 ASSEMBLY MANUAL The Yorktown gym is built using the frame of the Lexington gym as a base structure. When assembling the this gym, set aside the Lexington instructions and follow the steps in this document. Please read the owner’s manual before assembling your play set.

  • Page 2: Assembly Safety

    • Until assembly is complete, DO NOT let your children use the play set. • Never fasten anything not approved by Creative Playthings to your play set. Accessories or items not ap- proved by Creative Playthings include; Dog runs, clothes lines, electrical devices, or bird feeders etc.

  • Page 3: Safe Play Area

    • The Yorktown play set has ground dimensions of 7'-3" x 8'-8" (Swing Accessories not included). • The Yorktown play set requires a level ground surface of 19'-3" x 20'-8" for a Safe Play Area (Swing Accessories not included). • Additional accessories may increase the size of the Safe Play Area.
  • Page 4 Lag Screw 1/4 x 2-1/2" Hex Bolt 5/16 x 4-1/2" Lag Screw 1/4 x 1-1/2" Hex Bolt 5/16 x 5-1/2" Hex Bolt 1/4 x 1" Hex Bolt 3/8 x 6" YORKTOWN Page 4 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 5 17001-103 Weld Nut 3/8" CREATIVE PLAYTHINGS PLAY SETS USE A FEW STANDARD CONNECTIONS. BECOMING FAMILIAR WITH THESE CONNECTIONS WILL SIMPLIFY ASSEMBLY AND INSURE A SAFER PLAY PRODUCT FOR YOUR CHILDREN. Hex Bolt & Weld Nut Assembly Procedure: Assembly Layout: Align the holes in the parts to be fastened.
  • Page 6 G* 2 32408-102 Narrow Platform Board 5/4 x 4 x 76-3/4" 2 14179-400 Deluxe Hand Grip, Green 1 40422-102 Access Ladder Assembly 1 15133-400 Slide Mount, Green 1 50334-700 Hardware Bag, SP (2005) 1 50345-100 Hole Cap Pack YORKTOWN Page 6 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)

  • Page 7: Component Parts

    AL 1 33451-102 Sandbox Front 2 x 6 x 42-5/8" 1 33478-102 Safety Rail 2 x 4 x 100-1/2" 1 50490-700 Hardware Pack, Yorktown-Ridgefield AM 1 32847-402 Ridge Cap Pt A, 5/4 x 3-5/32 x 82-1/4" AN 1 32848-402 Ridge Cap Pt B, 5/4 x 2-9/32 x 82-1/4"...

  • Page 8: Maintenance Instructions

    Tighten as required and specified in these instructions. Do not over tighten. • Check structure twice monthly during usage for any evidence of deterioration. If upon inspection, hardware has sharp edges, rusted or structural pieces have signs of premature failure; replace them through Creative Playthings Customer Service.
  • Page 9 ASSEMBLY INSTRUCTIONS The Yorktown gym is built using the frame of the Lexington gym as a base structure. When assembling the this gym, set aside the Lexington instructions and follow the steps in this document. Step 1 — Sandbox Base & Corner Posts: Note: The large hole at the Separate and identify hardware and components.
  • Page 10 5/16 x 4" Hex Bolt Assemblies as shown. Fasten the remaining Sandbox Side (M) to the Porch Corner Posts using four 5/16 x 4" Hex Bolt Assemblies. YORKTOWN Page 10 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 11 Posts at one end of the structure using one 5/16 x 4" Hex Bolt Assembly in the top holes (only) as shown at right. Repeat with the Platform Back (R) on the opposite Posts. YORKTOWN Page 11 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 12 Outside Stringers are aligned across their bottom edges. (The holes in the Outside Stringers are offset from the center of the board; you may have to flip the board to achieve proper alignment.) YORKTOWN Page 12 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 13 Post. Note: There will be two extra holes in both the Platform Front and Platform Back that will not be used on the Yorktown as- sembly. Use Hole Caps to cover the extra holes.
  • Page 14 Boards as shown. The edge of the boards should align with the corner of the adjacent Post. Fasten the Narrow Platform Boards to the Stringers with eight #8 x 2" Flat Head Wood Screws for each board. YORKTOWN Page 14 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 15 Step 18 — Side Wall Support: Fasten the Side Wall Support (L) to the Porch Corner Posts above the Right Platform Side using four 5/16 x 4" Hex Bolt Assemblies. YORKTOWN Page 15 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 16 Weld Nut into the top hole and 3/8" Weld Nuts from the holes before moving to the step 20. beam hardware bag in the bottom holes before moving to the step 20. YORKTOWN Page 16 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 17 (AR) and the Door & Window Panel (AS) using four 1/4 x 2-1/2" Lag Screws and 1/4" Flat Washers each. Pilot drill for each Lag Screw using a 1/8" diameter drill. YORKTOWN Page 17 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 18 Ridge Cap Part A and into Ridge Cap Part B. Leave the screw head flush to the surface of Ridge Cap Part B (AN) Ridge Cap Part A. Ridge Cap Part A (AM) YORKTOWN Page 18 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 19 Panel Blocks using the same method. 3 — Fasten one End Panel Cap, as shown using six #8 x 1-5/8" Screws. Build a second Panel Frame with the remaining parts. YORKTOWN Page 19 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)

  • Page 20: Step 30 - Panel Board

    Gable Fan as shown. Use four #8 x 1-5/8" Screws. Repeat with the other Gable Filler at the other end of the roof. YORKTOWN Page 20 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)

  • Page 21: Step 32 - Safety Rail

    Fasten the Hand Grips (H) to the Entrance Slats (AI) using two 1/4 x 1" Hex Bolt Assemblies each. The Deluxe Hand Grip should be oriented as shown in the illustration. YORKTOWN Page 21 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 22 Platform Board and continue with assembly. It may help to clear space for the Weld Nut but using a 1" paddle bit on the underside of the Platform Board YORKTOWN Page 22 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 23 Make a final check and make sure that all the bolts and screws have been tightened. Locate the 1" Hole Caps in the hardware bag. Install Hole Caps into all the counter-bored holes to cover and protect the hardware. YORKTOWN Page 23 © Copyright 2010, Creative Playthings 19794-300 Rev J (05-20)
  • Page 24 Save all instruction sheets and receipts in case it becomes necessary to con- tact Creative Playthings for warranty service and/or part replacement. The warranty can be found in your Owner’s Manual. Please fill out the warranty card on the back of your owners manual. Your completed warranty card will allow us to quickly process warranty claims.
