Installation
Electrical power requirements
The module operates from an AC power input. Check that your location provides the proper electrical power requirements as
listed in the following tables.
AC line power.
Use the proper power cord with the module. (See page 2, International power cords.) The following table
lists the power requirements for the module.
Table 2: AC line power requirements
Parameter
Line voltage range
Line frequency
Maximum power
WARNING. In the module, only the line conductor is fused for over-current protection. The fuse is internal and not user
replaceable. Do not attempt to replace the fuse. If you suspect the fuse has blown, return the unit to an authorized
service center for repair.
Physical characteristics
The following table lists the physical characteristics of the Dual Display.
Table 3: Physical characteristics
Parameter
Dimensions
Height
Width
Depth
Weight
Net
Shipping
4
Description
100 - 240 VAC
WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage
fluctuations do not exceed 10% of the operating voltage range.
50/60 Hz
1.5 A
Description
13.28 cm (5.23 in.)
48.26 cm (19 in.)
7.62 cm (3 in.)
2.73 kg (6.02 lbs.)
Typically 4.54 kg (10 lbs.)
