Operating requirements

This section provides the environmental and power operating requirements for the module.
Environmental operating requirements
Check that the location of your installation has the proper operating environment as listed in the following table.
CAUTION. Damage to the module can occur if this module is powered on at temperatures outside the specified temperature
range.
Table 1: Environmental requirements
Parameter
Temperature Operating
Non
Operating
Humidity Operating
Non
Operating
Altitude Operating
Non
Operating
Cooling
Bare
Instrument
PRISM MPX2-DUALDSP Installation and Safety Instructions
Description
0 °C to +40 °C
–20 °C to +60 °C
20% to 80% relative humidity (% RH) at up to +40 °C, non-condensing
5% to 90% relative humidity (% RH) at up to 40 °C and derated linearly to 45% RH at
60 °C, non-condensing
To 3,000 m (10,000 feet)
Maximum operating temperature decreases 1 °C each 300 m above 1.5 km
To 12,000 m (40,000 feet)
Internal fans provide forced air circulation. Do not block ventilation openings.
To ensure proper airflow, there must be at least 2 inches of clearance on both sides of
the instrument, at least 2 inches of clearance from the rear of the instrument, and at
least a 1/2 inch of clearance from the top of the instrument.
