Documentation

Table i: Product documentation
Document
PRISM MPX2
Installation and
Safety Instructions
PRISM MPI2
and MPX2 User
Manual
PRISM MPX2
Rackmount
Slides and
Rails Installation
Instructions
Searching for documents on www.tek.com/downloads
The fastest way to find a document on tek.com is through filtering. Using the filtering options on the left side of the Web
page will help narrow down your choices until you find the correct documentation.
The following example lists six steps on searching for the latest User Manual:
1. Go to www.tek.com/downloads and search for PRISM.
2. Filter by Manual in the Filter by Type menu.
3. Filter by Primary User in the Filter by Manual Type menu.
NOTE. The Manual Type for each document is in the second column of the product documentation table. (See Table i.)
4. Sort by Date above the search bar.
5. The first manual in the list should be the latest PRISM User Manual. Click the link to the manual for additional information
and to download.
6. To confirm that you have the correct manual, look at the P/N and the Last Update date. This information is found below
the Download this manual link. See the image below for an example of the location.
NOTE. The first seven numbers of the P/N are the Tektronix part number from the product documentation table. The last
two numbers are the revision level number.
PRISM MPX2-DUALDSP Installation and Safety Instructions
Tektronix part
Manual type number
User 071-3629-xx
Primary User 077-1522-xx
Field Install 071-2746-xx
Instructions
Description
Describes how to install the
instrument and provides basic safety
and operating information
Provides detailed operating
information for the PRISM waveform
monitor
Describes how to install the
MPX2 instrument in a 19" equipment
rack
Preface
Availability
Print Web
√ √
√
√ √
vii
