ELECTRICAL SPECIFICATIONS/EQUIPMENT CLASSIFICATION
The Model SC-3004-DL interior components are "double insulated" and do not require a
"protective ground." The system is equipped with an 18 gauge, 2-wire, 10ft. Power cord, se-
cured through the pump casing with a Heyco strain relief brushing as well as an additional
"hold-down" clamp for added safety.
1. Class of protection against electrical shock: CLASS II EQUIPMENT
2. The degree of protection against electric shock: APPLIED PART-TYPE B
3. Mode: CONTINUOUS OPERATION WITH INTERMITTENT LOADING
4. According degree of protection against ingress of water: IP20
The model SC-3004-DL is intended for use in the electromagnetic environment specified below. The customer or the user of the model SC-3004-DL should assure
that it is used in such an environment.
Emissions test
RF emissions
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations / flicker
emissions
IEC 61000-3-3
The model SC-3004-DL is intended for use in the electromagnetic environment specified below. The customer or the user of the model SC-3004-DL should assure
that it is used in such an environment.
Immunity test
Electrostatic ± 2, 4, and6 kV contact
discharge (ESD)
IEC 61000-4-2 ± 2, 4 and 8 kV air
Electrostatic ± 2 kV for power supply lines
fast transient / burst
IEC 61000-4-4 ± 1 kV for input / output lines
Surge ± 0.5 and 1 kV line(s) to line(s)
IEC 61000-4-5 ± 2 kV line(s) to earth
Voltage dips, short <5 % U
interruptions and voltage
variations on power supply 40 % U
input lines
70 % U
IEC 61000-4-11
<5 % U
Power frequency (50/60 3 A/m
Hz) magnetic field
IEC 61000-4-8
NOTE: U is the AC mains voltage prior to application of the test level.
T
EMC Manufacturer's Declaration
Model SC-3004-DL electromagnetic emissions—manufacturer's declaration
Compliance
Group 1 The model SC-3004-DL uses RF energy only for its internal functions. Therefore, its RF emissions are
very low and are not likely to cause any interference in nearby electronic equipment.
Class B
Not applicable
The model SC-3004-DL is suitable for use in all establishments, including domestic establishments and
those directly connected to the public low voltage power supply network that supplies building used
for domestic purposes.
Not applicable
Guidance and manufacturer's declaration—electromagnetic immunity
IEC 60601
test level
(>95% dip in U ) for 0.5 cycles
T T
(60% dip in U ) for 6 cycles
T T
(30% dip in U ) for 30 cycles
T T
(>95% dip in U ) for 5 s
T T
Electromagnetic environment— guidance
Compliance level
± 2, 4, and6 kV contact
± 2, 4 and 8 kV air
± 2 kV
Not applicable
± 0.5 and 1 kV differential mode
Not applicable, no ground wire
<5 % U (>95% dip in U ) for 0.5 cycles
T T
40 % U (60% dip in U ) for 6 cycles
T T
70 % U (30% dip in U ) for 30 cycles
T T
<5 % U (>95% dip in U ) for 5 s
T T
3 A/m
17
Electromagnetic environment—guidance
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic ma-
terial, the relative humidity should be at least
30%.
Mains power quality should be that of a
typical home use location.
Mains power quality should be that of a
typical home use location.
Mains power quality should be that of a
typical home use location. If the user of the
model SC-3004-DL requires continued opera-
tion during mains power interruptions, it is
recommended that the model SC-3004-DL be
powered from an uninterruptible power
supply or a battery.
The power frequency magnetic fields should
be at the levels found in a typical home use
location.
