TROUBLESHOOTING

If the corrective action does not solve the problem, then call Bio Compression Systems, Inc.,
at 1-800-888-0908. Be sure to have serial number available when calling for service.
Symptom
The device is not working.
One garment inflates but the
second one does not.
The device is making strange
and/or loud noises.
Regardless of the pressure
setting the garments are
applying a very low pressure.
NOTE: In addition to possessing proper tools and testing equipment, authorized service
personnel have access to all electrical schematics, calibration instrumentation and
criteria and an inventory of authorized replacement parts.

CLASSIFICATION:

1. Class of protection against electrical shock
CLASS II EQUIPMENT
2. The degree of protection against electric shock
APPLIED PART—TYPE B
3. Mode
Continuous operation with intermittent loading or one hour timed
4. According degree of protection against ingress of water: IP20
(without protection against ingress of water)
Possible Cause
No electricity
Power cord
The second garment is not
receiving air.
Device is on a uneven or
unstable surface
An internal problem
Defective Garment
An internal problem
15
Corrective Action
Check the electrical wall outlet to be sure that
the pump is plugged into the outlet correctly.
Check the circuit breaker to be sure there is
power to the outlet.
Unplug the power cord and look for any
damage or defects.
Check the garment hoses for adequate connec-
tion to the device, kinks, punctures, twists and /
or folds.
Move to a more stable surface.
Contact Bio Compression Systems, Inc., for
repair.
Check the garment for adequate connection to
the device, leaks, kinks, punctures, twists and /
or folds.
Contact Bio Compression Systems, Inc., for
repair.
