- Page 1 Bio Compression Systems, Inc. Model IC-BAP-DL BioArterial Plus Arterial Blood Flow Enhancement System U.S. BASED MANUFACTURER Quality Medical Products Since 1983...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................3 Important Safety Information ................3 Symbol Definitions ....................3 Warnings ......................3 Basic Safety Precautions ..................4 General Equipment Specifications ..............4 Indications For Use ..................... 5 Contraindications ....................5 Systems and Components ..................6 Controls and Display ................... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your BIO COMPRESSION SYSTEMS MODEL IC-BAP-DL BIO ARTERIAL PLUS Arterial Blood Flow Enhancement System and garments. The BIO ARTERIAL PLUS is an Intermittent, Sequential, Pneumatic Compression System that se- quentially compresses both the foot and calf in patients suffering primarily from diabetic foot ul- cers or intermittent claudication (leg pain primarily from decreased arterial circulation). -
Page 4: Basic Safety Precautions
Keep this device out of reach of children or pets. Do not take the pump, garment or tubing apart. Use only accessories that are recommended by Bio Compression Systems, Inc. Never use pins or other metallic fasteners with this product. -
Page 5: Indications For Use
INDICATIONS FOR USE The Bio Arterial Plus Arterial Blood Flow Enhancement System is intended as an ad- junct therapy for patients with ischemic disease of the lower extremities, due to one or more of the following causes: Rest or Night Pain ... -
Page 6: Systems And Components
SYSTEM AND COMPONENTS The BIO ARTERIAL PLUS system is comprised of the Controller/Pump along with a set of bilateral garments with color coded tubing and contrasting style “quick” connectors. CONTROLS AND DISPLAY (A) Velcro-type attachment tab (FOOT) (B) Velcro-type attachment tab (UPPER CALF) (C) Velcro-type attachment tab (MID CALF) (D) Tube connector to pump (FOOT) (E) Tube connector to pump (CALF) -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Place the pump on a sturdy table or any other flat surface close to where you will be sitting. The pump has non-slip rubberized feet on the bottom. Placing anything under the pump can cause the unit to slide or move. ... - Page 8 NORMAL POWER-UP SEQUENCE On a normal power-up sequence, the IC-BAP-DL Bio Arterial Plus will go through the following: Current Mode Setting will be displayed for three seconds. Current Pressure Setting will be displayed for four seconds. Unit will now start running as along as the Valve was stopped in the correction location, other- wise a twenty second countdown will start to allow the valve to rotate to the correct starting position.
-
Page 9: Maintenance And Storage
While the unit is running, press and hold the DOWN button first, then press and hold down the POWER button. Both buttons must be held down together for five seconds. If the DOWN button is accidentally released and the POWER button is still being pressed, the unit will turn off. After both buttons have been held down for five seconds, the display will show “rES”. -
Page 10: Packaging, Shipping & Storage
(3.0 Amp FSL). NOTE: The outer safety fuse is the only item serviceable by someone other than a Bio Compression Systems technician at the factory. Bio Compression Systems tech- nicians have been trained specifically for the manufacturing and repair of all Bio... -
Page 11: Troubleshooting
TROUBLESHOOTING If the corrective action does not solve the problem, then call Bio Compression Systems, Inc. Be sure to have serial number available when calling for service. Symptom Possible Cause Corrective Action No electricity. Check the electrical wall outlet to be sure that the pump is plugged into the outlet correctly. -
Page 12: Equipment Classification/Electrical Specifications
ELECTRICAL SPECIFICATIONS/EQUIPMENT CLASSIFICATION The Model IC-BAP-DL Bio Arterial Plus interior components are “double insulated” and do not require a “protective ground.” The system is equipped with an 18 gauge, 2-wire, 10ft. Power cord, secured through the pump casing with a Heyco strain relief brushing as well as an additional “hold-down”... - Page 13 Guidance and manufacturer’s declaration — electromagnetic immunity The model IC-BAP-DL is intended for use in the electromagnetic environment specified below. The customer or the user of the model IC-BAP-DL should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment—guidance...
-
Page 14: Warranty Information
Compression Pump = 3 years from date of purchase / invoice Sleeves/Garments = 1 year from date of purchase / invoice Serial Number: ____________________________________ Date Purchased: ___________________________________ Local Representative/Dealer: ________________________ Phone Number: ____________________________________ FOR ALL REPAIR SERVICES PLEASE CALL TECHNICAL SUPPORT AT: Bio Compression Systems, Inc.
