Lockly SECURE PRO Installation Manual page 8

Step 2
Check the exterior assembly (B) alignment
to door hole and deadbolt before peeling
off film on adhesive strips.
Peel film from adhesive strips and make sure torque blade is in the vertical position with
the deadbolt extended. Place assembly and torque blade through the deadbolt slot
and guide connection cables through the cross-bore hole under the deadbolt as shown.
Complete mounting by aligning and securing until flush to exterior door surface.
Extended
INSTALLING EXTERIOR ASSEMBLY (B)
Vertical
6
B
Adhesive tape
M
Under
EXTERIOR VIEW
