  • Page 2: Table Of Contents

    CONTENTS 1. Safety Instructions ..................2 2. Technical Specifications ................. 4 3 Control Panel ....................6 4. Color/Gobo and Lamp ..................7 4.1 Color/Gobo ....................7 4.2 Light Source ..................... 7 4.3 Change The Lamp ..................8 5. How To Set The Unit ..................9 5.1 Main Function ..................

  • Page 3: Safety Instructions

    1. Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
  • Page 4 off the mains power immediately. DO NOT operate in dirty or dusty environment, do clean fixtures regularly.  DO NOT touch any wire during operation as there might be a hazard of electric shock.  Avoid power wires together twist other cables. ...

  • Page 5: Technical Specifications

    2. Technical Specifications Power Voltage: AC 100~240V, 50/60Hz Power Consumption: 535W Light Source: Philips MSD Platinum 16R Color Temperature: 8000K Beam Angle: Beam Mode: 2.3°~8° Spot Mode: 6°~22° Wash Mode: 22°~63° Movement: Pan: 540° Tilt: 270° Pan/Tilt Resolution: 16 bit Dimmer/Shutter: Smooth dimming from 0-100%;...
  • Page 6 Construction: Display: LCD display Date In/Out: 3-pin&5-pin XLR Power In/Out: Power Connector in Protection Rating: IP20 Features: Motorized focus Linear CMY color mixing 8 facet prism+ 16 facet prism, both of them can rotate in both directions and overlay each other Outstanding color macro effect Independent frost effect Integrated three features: beam, spot, and wash...

  • Page 7: Control Panel

    3 Control Panel 1. Display: To show the various menus and the selected function 2. LED: POWER Power On DMX input present 3. Button: MENU To enter into move backward or leave the menu To go backward to move up in the menu DOWN To go forward to move down in the menu ENTER...

  • Page 8: Color/Gobo And Lamp

    4. Color/Gobo and Lamp 4.1 Color/Gobo DANGER! Install the color wheel/gobo wheels with the device switched off only. Unplug from mains before changing the color wheel/gobo wheels! CAUTION: Never unscrew the screws of the rotating gobo as the ball bearing will otherwise be opened! 4.2 Light Source Philips MSD Platinum 16R...

  • Page 9: Change The Lamp

    4.3 Change The Lamp Do not use this lamp more than 1000 hours, using the lamp any longer than its set life could seriously damage your unit. Periodically checking the lamp running time, when the lamp reaches the 1000 hour mark, or close to it, we strongly suggest you switch the lamp out. Clear the RESET TIME after you have replaced the lamp.

  • Page 10: How To Set The Unit

    Warning: The installing direction of lamp: 5. How To Set The Unit 5.1 Main Function Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until the required function is shown on the monitor. Select the function by the ENTER button. Use the UP/DOWN button to choose the submenu, press the ENTER button to store and automatically return to the last menu.
  • Page 12 DMX Functions To select DMX Functions press the ENTER button to confirm, use the UP/DOWN button to select DMX Address, DMX Channel Mode, DMX State or View DMX Value. DMX Address —DMX512 address setting To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the address from 001 to 512, press the ENTER button to store.
  • Page 13 Pan Inverse To select Pan Inverse, press the ENTER button to confirm. Use the UP/DOWN button to select No (normal) or Yes (pan inverse), press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Tilt Inverse To select Tilt Inverse, press the ENTER button to confirm.
  • Page 14 Lamp Settings To select Fixture Settings, press the ENTER button to confirm, use the UP/DOWN button to select Lamp On/Off or State/Power on. Lamp On/Off —Turn on/off the lamp To select Lamp On/Off, press the ENTER button to confirm. Use the UP/DOWN button to select On(lamp on) or Off(lamp off), press the ENTER button to store.
  • Page 15 Temperature Unit Select Temperature Unit, press the ENTER button to confirm, present mode will blink on the display, use the UP/DOWN button to select ℃ or ℉, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Fixture Test Enter menu mode, select Fixture Test, press the ENTER button to confirm, use the UP/DOWN button to select Auto Test or Manual Test...
  • Page 16 Light On Time Select Light On Time, press the ENTER button to confirm, present mode will blink on the display, use the UP/DOWN button to select Exit or Reset time. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode. Temperature Select Temperature, press the ENTER button to confirm, fixture temperature will show on the display, press the MENU button to exit.
  • Page 17 Effect —Reset Effect Select Effect, press the ENTER button to confirm, use the UP/DOWN button to select Yes (the unit will run built-in program to reset effect to their home positions) or No, press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode.

  • Page 18: Home Position Adjustment

    Select the PAN INVERT menu and the fixture will run the pan invert mode. Select the TILT INVERT menu and the fixture will run the tilt invert mode. Select the RESET DEVICE menu, the WARM RESET/COLD RESET option will be displayed. When WARM RESET is selected, the fixture will start a warm reset, and exit when COLD RESET is selected.
  • Page 19 Pan—pan home position adjustment Enter offset mode, Select Pan, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Tilt—Tilt home position adjustment Enter offset mode, Select Tilt, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button...
  • Page 20 Gobo1—Gobo1 home position adjustment Enter offset mode, Select Gobo1, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to store. Press the MENU button to exit. Gobo2—Gobo2 home position adjustment Enter offset mode, Select Gobo2, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER...

  • Page 21: Control By Universal Dmx Controller

    Focus—Focus home position adjustment Enter offset mode, Select Focus, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from 0 to 255, press the ENTER button to store. Press the MENU button to exit. Zoom—Zoom home position adjustment Enter offset mode, Select Zoom, press the ENTER button to confirm, the present position will blink on the display, use the UP/DOWN button to offset the value from 0 to 255, press the ENTER button...

  • Page 22: Address Setting

    2. Connect the unit together in a “daisy chain” by XLR plug cable from the output of the unit to the input of the next unit. The cable cannot be branched or split to a “Y” cable. DMX 512 is a very high-speed signal.

  • Page 23: Dmx512 Configuration

    6.3 DMX512 Configuration Please refer to below configurations to control the fixtures Attentions: 1. The unit will maintain the last condition until reset if you cut-off the DMX signal. 2. For the channel Function, keep the value for about 5 seconds, then the corresponding function will take into effect.
  • Page 24 006-008 Gobo 2 009-011 Gobo 3 012-014 Gobo 4 015-017 Gobo 5 018-020 Gobo 6 021-023 Gobo 7 024-026 Gobo 8 027-029 Gobo 9 030-032 Gobo 10 033-035 Gobo 11 036-038 Gobo 12 039-041 Gobo 13 042-044 Gobo 14 044-054 Gobo 15 055-058 Gobo 1 shaking slow to fast...
  • Page 25 103-107 Gobo 5 shaking slow to fast 108-112 Gobo 6 shaking slow to fast 113-117 Gobo 7 shaking slow to fast 118-122 Gobo 8 shaking slow to fast 123-127 Gobo 9 shaking slow to fast 127-189 Clockwise Rotation Fast to Slow 190-193 Stop 194-255...
  • Page 26 FROST 000-007 Close 008-255 Open SOFTEN 000-007 Close 008-255 Open Special Function 000-069 No Function 070-079 Blackout While Pan Tilt Move Enable 080-089 Blackout While Pan Tilt Move Disable 090-099 Blackout While Color Move Enable 100-109 Blackout While Color Move Disable 110-119 Blackout While Gobo Move Enable 120-129...
  • Page 27 006-011 Color 1 012-017 Color 2 018-023 Color 3 024-029 Color 4 030-035 Color 5 036-041 Color 6 042-047 Color 7 048-053 Color 8 054-059 Color 9 060-127 White to Color 9 128-189 Clockwise Rotation Fast to Slow 190-193 Stop 194-255 Counter-Clockwise Rotation Slow to Fast GOBO WHEEL 1...
  • Page 28 194-255 Counter-Clockwise Rotation Slow to Fast GOBO WHEEL 2 000-006 White 007-013 Gobo 1 014-020 Gobo2 021-027 Gobo 3 028-034 Gobo4 035-041 Gobo 5 042-048 Gobo 6 049-055 Gobo 7 056-062 Gobo 8 063-083 Gobo 9 084-087 Gobo 1 shaking slow to fast 088-092 Gobo 2 shaking slow to fast 093-097...
  • Page 29 252-255 Light ON DIMMER 000-255 0%100% FOCUS 000-255 0%100% 000-255 FOCUS FINE ZOOM 000-255 100%0% 000-255 ZOOM FINE FROST 000-007 Close 008-255 Open SOFTEN 000-007 Close 008-255 Open Special Function 000-069 No Function 070-079 Blackout While Pan Tilt Move Enable 080-089 Blackout While Pan Tilt Move Disable 090-099...

  • Page 30: Troubleshooting

    7. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connect power and main fuse. 2.
  • Page 31 Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU. EN 55032: 2015; EN 61000-3-2: 2014; EN 61000-3-3: 2013; EN 55103-2: 2009. &...
  • Page 32 Innovation, Quality, Performance...
