Install AC Power Cables
Hardware Installation Guide
44
Figure 19 Single-phase power distribution
Zone A
Zone A
Table 9 Single-phase power distribution cabling (from top to bottom)
Source
Node 32 PSU1
Node 32 PSU2
Node 31 PSU1
Node 31 PSU2
Node 30 PSU1
Node 30 PSU2
Node 29 PSU1
Node 32
Node 31
Node 17
Data Switch D
Data Switch A
Mgmt Switch B
1U spare for cable routing
Mgmt Switch A
Mgmt Server
Node 16
Node 1
Destination
PDU 1 Port 2
PDU 2 Port 2
PDU 1 Port 2
PDU 2 Port 2
PDU 1 Port 3
PDU 2 Port 3
PDU 1 Port 3
Zone B
Zone B
