1U1N Configuration Equipment Installation
Hardware Installation Guide
30
Component
Description
Function
Management Server
Management Server
Management Switch
Customer provided 1
GbE switch
Data Switch
Customer provided 10
GbE switch
Table 8 Maximum configuration in 3-phase wye power
distribution cabinets (continued)
Quantity
1
2
2
Cabinet U Space
18
19 - 20
21 - 24
